Soakaways, sometimes referred to as soak pits or infiltration trenches, are essential components of drainage systems used to manage surface water effectively. These underground structures play a crucial role in preventing flooding and groundwater pollution by allowing rainwater to slowly percolate into the ground. In this post, we will delve into what soakaways are, their benefits, design considerations, and installation processes.
What is a Soakaway?
A soakaway is a subsurface structure designed to manage excess surface water, particularly rainwater, and direct it into the ground. This process facilitates the natural infiltration of water into the soil, ultimately recharging the groundwater and reducing the risk of surfacewater flooding. Soakaways are commonly used in both residential and commercial settings to control rainwater runoff and prevent waterlogging.
Benefits of Soakaways
Flood Prevention: Soakaways help mitigate the risk of flooding by efficiently diverting rainwater away from the surface, reducing the strain on drainage systems.
Water Quality Improvement: As water percolates through the soil, it undergoes natural filtration, which improves water quality by removing contaminants and pollutants.
Groundwater Recharge: Soakaways contribute to the recharge of underground aquifers, which is vital for maintaining a sustainable water supply.
Environmental Sustainability: Soakaways are eco-friendly solutions that reduce reliance on complex drainage systems and promote a more natural water management approach.
Soakaway Design Considerations
When designing a soakaway, several factors must be considered to ensure its efficiency and longevity:
Permeability of Soil: The type and permeability of the soil in the area play a crucial role. Highly permeable soils, such as sandy or gravelly soils, are ideal for soakaways, while clay soils may require larger soakaways or alternative solutions.
Water Table: The depth of the groundwater table should be known to prevent interference with the soakaway's function.
Rainfall Data: Accurate rainfall data for the area is essential to determine the soakaway's capacity and design it accordingly.
Size and Shape: The size and shape of the soakaway depend on the anticipated volume of surface water runoff. It should be adequately sized to handle the expected rainfall.
Location: Soakaways should be strategically located to efficiently collect water from surfaces like roofs and driveways. They must also adhere to local regulations regarding setbacks and proximity to buildings.
Maintenance Access: Ensure there is adequate access for inspection and maintenance purposes, such as cleaning and removing silt or debris.
Soakaway Installation
The installation of a soakaway involves several key steps:
Percolation Test: Before installation, a percolation test is conducted to assess the soil's permeability and determine the soakaway's required size.
Excavation: A pit or trench is excavated to the required depth and dimensions, considering the design specifications.
Geotextile Membrane: A geotextile membrane is placed at the base and sides of the excavation to prevent soil from clogging the soakaway.
Inlet and Outlet Pipes: Inlet pipes are connected to the surface water source (e.g., roof or driveway) to direct water into the soakaway. Outlet pipes allow excess water to drain away if the soakaway reaches its capacity.
Fill Material: Stone or gravel fill material is added to the excavation, forming the body of the soakaway. This material provides voids for water storage.
Maintenance Access: An inspection chamber or manhole is constructed to allow access for maintenance and cleaning.
Backfill: The excavation is backfilled with soil and compacted to ensure stability.
Final Surface: The final surface is reinstated, and any landscaping or surface features are restored.
In conclusion, soakaways are valuable components of sustainable drainage systems that help manage surface water effectively, reduce the risk of flooding, improve water quality, and contribute to groundwater recharge. The design, installation, and maintenance of soakaways must be approached with careful consideration of factors such as soil type, rainfall, and local regulations to ensure their success. By incorporating soakaways into drainage plans, individuals and communities can play a vital role in responsible water management and environmental preservation.
